A155 Recessed Down Light 6-inch $120.45
  • Image 1
  • Image 2
  • Image 3
  • Image 4

A155 Recessed Down Light 6-inch

$120.45
SKU:
ILIM6660
Availability:
Ships in 1-2 days
Shipping:
Calculated at checkout
Quantity:

Product Description

IMTRA Marine A155 6-inch Recessed Down Light

The brand new A155  6-inch down light from Imtra Featuring 2-wire power & dimming, the A105/155 PowerLED fixtures easily replace existing legacy (halogen) spots negating the need to run extra wires. Integrated drive electronics eliminates the need for remote driver installation. Carefully designed optics result in fully blended illumination free of annoying artifacts or distracting hot spots. A robust thermal management system results in maximum life with minimal lumens depreciation over its expected working life (50,000+ hrs). A105/155 models offer single or bi-color dimming when paired with Imtra's single or dual channel PWM dimmer module. These models feature a low profile round bezel in polished stainless or white powder coat finish. The A105/155 PowerLED fixtures conveniently & firmly installs with self-adjusting stainless steel springs. Made in the USA and covered by a 5 year warranty!



Specifications:

Trim Ring (Bezel) Finish/Material White or Polished Chrome
Housing Finish/Material 316 Stainless Steel
Lens Material Frosted Glass
Trim Ring (Bezel) Dimensions 6.10" (155mm)
Cut-out Dimensions 5.36" (136mm)
Recessed Depth 1.35" (35mm)
Dimensions See Dimensional Drawing
Integrated Switch No
Voltage 10-40VDC
Halogen Equivalency 25W
Power Consumption 4.7W
Driver Integrated
Output Color Select from Options Menu
Lumens 216 Lumens
Correlated Color Temperature (CCT) 6000K
Color Rendering Index (CRI) 85
Lifetime Hours 50,000 hrs
Dimmer Compatibility ILIM80130, ILIM80140
Dimmer Control Interface Momentary Push-Button
Dimming Range 5-100%
Install Location Ceilings (interior)
Ingress Protection IP65 (applies only to frontal water exposure, i.e. Exposed surface)
Class III
Electrical Protections Reverse Polarity, Transient & Spike Protection
Certifications & Compliance CE-EMC, ROHS
Manufacturer Imtra
Warranty 5 Years / 1 Year Finish




Warranty Information

5-YEAR WARRANTY

Other Details

Volts:
12/24VDC
Watts:
25W
Light Type:
LED
Cutout:
5.31" Hole
Mounting:
Springs
Waterproof:
Yes
